Rear Differential Repair Panel including Filler Plug For Land Rover Defender 90 (1987-2016)

Keep your rear axle oil-tight and protected with our heavy-duty Rear Diff Repair Pan. Designed specifically for the Land Rover Defender 90, this replacement pan is the ideal solution for repairing axle casings that have suffered from severe corrosion or impact damage during off-road use.

Structural Security The differential pan is a notorious trap for mud and moisture, which often leads to the metal thinning and eventually weeping oil. This high-grade steel repair pan is engineered to replace the thin, factory-pressed face, providing a fresh, durable surface that can withstand the rigours of both daily driving and heavy overland expeditions.

Accurate Engineering The MA021044 is pressed to match the specific curvature and dimensions of the Defender 90 rear axle. It is designed to be welded onto the existing casing once the damaged section has been removed, ensuring a permanent and structural repair that maintains the original oil capacity and clearance.

Key Features:

• Heavy-Gauge Steel: Manufactured for superior impact resistance against rocks and stumps.
• Weld-Ready: Precision-pressed edges for a cleaner welding process and an oil-tight seal.
• Corrosion Solution: The most reliable way to fix leaking differentials caused by "rust-through" on the axle casing.
• Bespoke Fit: Engineered specifically for the standard Defender 90 rear axle.
• Protective Base: Provides a clean, solid foundation for your choice of protective paint or waxoyl treatment.

Technical Specifications:

• Part Number: MA021044
• Application: Rear Axle Differential
• Compatibility: Land Rover Defender 90 (Standard Rover Axle).
• Material: High-Strength Press-Formed Steel

Installation Note: This is a weld-on component. To ensure a professional finish, the axle should be drained and the mounting surface thoroughly cleaned before welding.

Whether you are refurbishing an older chassis or repairing trail damage, the MA021044 Rear Diff Pan is a vital component for maintaining your Defender’s drivetrain integrity.
